Application
These mud flaps are designed for the Volkswagen Santana 3000 (Chaoyuezhe), a China-exclusive mid-size sedan built by Shanghai Volkswagen on the Passat B2 platform. Production spanned 2004 to 2008 for the Santana 3000, with its facelift successor Santana Vista (Zhijun) continuing from 2008 to 2012. Both variants share identical body panels and fender contours, making these mud flaps compatible across the full 2004-2012 range.
Vehicle Coverage
Volkswagen Santana 3000 (Chaoyuezhe): 2004-2008, 1.6L / 1.8L / 2.0L EA113
Volkswagen Santana Vista (Zhijun): 2008-2012, 1.6L / 1.8L / 2.0L EA113
Platform: Volkswagen Passat B2
Assembly: Shanghai Volkswagen, China
Platform Context
The Santana 3000 holds a unique place in Chinese automotive history as the first vehicle independently designed by the Shanghai-VW joint venture, rather than by Volkswagen Germany. It succeeded the Santana 2000 (1995-2004) and was itself succeeded by the Santana Vista (2008-2012). The entire B2-based Santana lineage in China produced over 3.5 million units, serving as the backbone of taxi fleets, government vehicles, and private buyers for nearly three decades.
Non-Compatible Models
Original Santana (Pu-Sang, 1985-2012): different body shell, shorter wheelbase (2,548mm vs 2,656mm)
New Santana (2013-2022): PQ25 platform, completely different vehicle
Gran Santana hatchback (2015-2022): different body style and platform
Aftermarket Supply Note
The Santana 3000 has been out of production since 2008 and the Vista since 2012. As a China-exclusive model with no direct successor on the same platform, these mud flaps serve the aftermarket and used-car export market. Buyers in Southeast Asia and the Middle East sourcing parts for legacy Chinese fleet vehicles will find these units applicable to both Santana 3000 and Vista sedans within the 2004-2012 production window.
Product Overview
Factory-spec mud flaps for the Volkswagen Santana 3000 and Vista, engineered to match the original fender contours of the B2-platform sedan. Each set includes four pieces covering front and rear wheel arches.
Specifications
Material: PP (polypropylene) soft plastic
Color: Black
Front wheel dimensions: 180 x 240mm
Rear wheel dimensions: 195 x 215mm
Quantity: 4 pieces per set (2 front + 2 rear)
Net weight: 0.40kg per set
Fastener ready: Yes
Material Properties
The PP soft plastic construction provides high elasticity and resistance to bending, maintaining flexibility across temperature ranges typical of Southeast Asian and Middle Eastern climates. The material is selected for its durability against stone chips, road salt, and mud accumulation without cracking or deformation.
Available Material Options
PP: Standard OEM-spec polypropylene, factory-original material grade
PP+TPE: Blended construction for enhanced cold-weather flexibility
TPE: Thermoplastic elastomer for premium aftermarket upgrade
ABS: Rigid option for maximum impact resistance
Fitment Guide
The following table outlines vehicle compatibility for these mud flaps. The Santana 3000 and its facelift successor Santana Vista share identical body panels and fender contours, allowing a single mud flap set to cover the full 2004-2012 production range.
Compatibility Matrix
Model | Years | Engine | Platform | Fit |
Santana 3000 (Chaoyuezhe) | 2004-2008 | 1.6L / 1.8L / 2.0L EA113 | Passat B2 | Yes |
Santana Vista (Zhijun) | 2008-2012 | 1.6L / 1.8L / 2.0L EA113 | Passat B2 | Yes |
Santana Vista Changda (Taxi) | 2008-2012 | 1.6L / 1.8L EA113 | Passat B2 | Yes (same body) |
Santana 2000 | 1995-2004 | 1.8L / 2.0L | Passat B2 (extended) | Similar body; verify fender profile |
Original Santana (Pu-Sang) | 1985-2012 | 1.6L / 1.8L | Passat B2 (standard) | No; different body shell |
New Santana | 2013-2022 | 1.4L / 1.5L | PQ25 | No; different platform |
Cross-Generation Notes
The Santana 3000 was developed from the Santana 2000, sharing the same 2,656mm wheelbase and body structure. Fender contours are understood to be compatible, but buyers should verify the 2000 model year against the specific fender profile.
The Santana Vista is a direct facelift of the 3000 with identical body dimensions. All four mud flap positions are fully interchangeable between 3000 and Vista.
The Vista Changda is a taxi-specific variant with different front grille styling but identical fender stamping. Mud flap fitment is unchanged.
The original Santana (Pu-Sang) uses a shorter wheelbase (2,548mm) and different fender stamping. These mud flaps will not fit the original Santana.
Installation and OEM Options
Installation of these Santana 3000 mud flaps requires the included fastener hardware set. The tool-assisted mounting process uses existing fender screw points without drilling or modification.
Fastener Hardware Included
Plastic Fender Fastener Clips: push-type retainers for primary mounting
U Clip Screws: secondary retention for secure fitment
Allen Screws with Hex Key: wheel-well attachment points
Installation Steps
Clean the wheel-well and fender edge surfaces
Position each mud flap against the corresponding fender contour
Insert plastic fastener clips into existing fender mounting holes
Secure with U clip screws at secondary points
Tighten Allen screws using the included hex key
Verify alignment and clearance with wheel rotation
OEM Material Reference
The original Santana 3000 mud flaps were manufactured from PP (polypropylene) to Shanghai-VW specifications. The aftermarket equivalents offered here match the original dimensions and material grade, providing equivalent splash protection performance. Four material options (PP, PP+TPE, TPE, ABS) are available to suit different climate and usage conditions.
Payment and Delivery
MOQ: 100 sets
Delivery Terms: FOB, CIF
Payment Type: T/T, L/C, Credit Card, Western Union
Payment Currency: USD, EUR, HKD
